Heat Shrink Tube - Medium Wall

Shrink polymer Systems



SPS TMC medium wall heat shrink tubing provides excellent electrical insulation to low and high voltage cables, joints and terminations - medium wall heat shrink tubing is suitable for exposed, underground direct buried and underwater applications.

SPS TMC medium wall heat shrink tubing features an adhesive lining for superior moisture ingress protection and sealing.

TMC 12-4, 4-12mm Medium Wall Heat Shrink Tubing for Protection & Sealing of LV, MV & HV Cables, Joints & Terminations

LV - Low Voltage

MV - Medium Voltage

HV - High Voltage

TMC medium wall heat shrink tubing provides tough and flexible insulation and is ideal for the protection of LV and HV cables, cable joints and terminations. TMC heat shrink is lined with a specially designed adhesive, which is applied during the tubings extrusion process achieving a very smooth adhesive layer, which ensures excellent sealing properties -  medium wall heat shrink tubing is suitable for exposed, underground direct buried and underwater applications.

Also available: LV, MV & HV Cable Joints & Cable Termination Kits

  • Heat Shrink Applications:
  • Strain relief and environmental protection
  • Cable splice covers for electrical cables
  • HVAC systems for pipes and ducts
  • Insulation cover or cable jacket repair on low voltage cables
  • Cable jointing, sealing and protection.
Part Number Shrink Range Wall Thickness Full Recovery
TMC 12-4 4-12mm 2.0mm
TMC 22-6  6-22mm 2.0mm
TMC 28-6 6-28mm  2.5mm
TMC 33-8 8-33mm  2.5mm
TMC 40-12 12-40mm  2.5mm
TMC 55-16  16-55mm  2.7mm
TMC 75-22 22-75mm 3.0mm
TMC 95-25 25-95mm  3.0mm
TMC 115-34  34-115mm  3.0mm
TMC 140-42 42-140mm  3.0mm
TMC 205-65  65-205mm  3.0mm



Adobe Heat Shrink Cable Joints & Cable Terminations LV HV, 6.6kV 11kV 33kV - SPS Catalogue

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 4-12mm - TMC12-4

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 6-22mm - TMC22-6

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 6-28mm - TMC28-6

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 8-33mm - TMC33-8

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 12-40mm - TMC40-12

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 16-55mm - TMC55-16

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 22-75mm - TMC75-22

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 25-95mm - TMC95-25

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 34-115mm - TMC115-34

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 42-140mm - TMC140-42

Adobe Heat Shrink Tube - Medium Wall Adhesive Lined 65-205mm - TMC205-65
